Elcometer 112 Aluminium Wet Film Comb: 25-3000µ
In stock
Technical detailSpecifications and technical detail for this instrument are on bamr.co.zaAbout Elcometer 112 Aluminium Wet Film Comb: 25-3000µ
These hexagonal precision formed stainless steel wet film combs are long lasting, reusable and supplied in a range of thicknesses measuring up to 3000μm.
These six-sided combs vary in size, giving either 24 or 36 measurement steps, depending upon the comb, thus providing increased accuracy.
These punched aluminium combs offer the user a low cost method of measuring the wet film thickness.
The Elcometer 112AL, being punched from aluminium, is not as accurate as precision formed stainless steel wet film combs and has a shorter lifespan.
The Elcometer 112AL can be customised with your logo. Please contact us for further details.
Technical Specifications
| Part Number | Range | Values | Certificate |
| K0003236M201 | 20 - 370µm | 20, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 130, 150, 170, 190, 210, 230, 250, 270, 290, 310, 330, 350, 370µm | ο |
| K0003236M202 | 25 - 2000µm | 25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000, 1100, 1200, 1300, 1400, 1500, 1600, 1700, 1800, 1900, 2000µm | ο |
| B112----1B | 25 - 3000µm | 25, 50, 75, 100, 125, 150, 175, 200, 225, 250, 275, 300, 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 1000, 1100, 1200, 1400, 1600, 1800, 2000, 2200, 2400, 2600, 2800, 3000µm | ο |
ο Optional Calibration Certificate available
| Accuracy | ±5% of marked value or 3μm (0.12mil) whichever is the greater |
|---|---|
| Elcometer 3236M201/M203 | 53 x 50 x 1mm (2.09 x 1.97 x 0.04”), 10g (0.35oz) |
| Elcometer 3236M202/M204 | 77 x 90 x 1mm (2.95 x 3.54 x 0.04”), 22g (0.77oz) |
| Elcometer 112 | 75 x 65 x 1mm (2.95 x 2.54 x 0.04”), 20g (0.7oz) |
| Packing List | Wet Film Comb, storage case and operating instructions |
