AZ 88463 Barometric, Temperature & Humidity Recorder
In stock
Technical detailSearch bamr.co.za for the specifications and technical detail on this instrumentAbout AZ 88463 Barometric, Temperature & Humidity Recorder
Bluetooth 4.0 data logger that records humidity, temperature and barometric pressure, with a free iOS and Android app ("Nice Logger") for PDF and CSV reports.
The 88463 AZ Bluetooth 4.0 Data Logger can measure the Humidity and Temperature and Barometric readings throughout the entire duration of the logging period. This data logger is equipped with Bluetooth communication for programming purposes, simplifying remote data logging and allowing the user to interact with the unit through their smartphone. A Bluetooth-integrated iOS and Android app is available, ensuring that reports and measurements can be shared seamlessly. Both PDF file and csv files can be generated by the free App "Nice Logger".
Features
- Log & download data wirelessly through advanced Bluetooth 4.0 technology
- Accurate temperature, barometric and humidity readings from the built-in sensor
- Record and collect data in seconds
- Free IOS & Android data logging App can be downloaded for smartphones - "Nice Logger" in the App store
- Use the App to download PDF reports containing summaries, graphs and detailed data measurements
- Big LCD screen and LED lights provide real time data every 5 seconds, with alarm and status indicators
- Historical readings can be accessed by checking Max and Min values
Applications
The 88463 AZ Bluetooth 4.0 Barometric, Temperature & Humidity Recorder is ideal for various uses, and is especially well-suited for warehouses, storerooms, laboratories, basements, wine cellars, industrial processing areas, industrial kitchens, HVAC fields or other controlled environments.
Supplied with
- 88463 AZ Barometric, Temperature & Humidity Recorder
- Instruction Manual
- Batteries
| Model | 88463 AZ Barometric, Temperature & Humidity Recorder |
|---|---|
| Temperature Range | NTC Thermistor, -30-70℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Accuracy | ±0.5℃ |
| Humidity Range | Capacitor, 0.1-99.9% RH |
| Humidity Resolution | 0.1% RH |
| Humidity Accuracy | ±3%RH (at 25℃ 10-90%RH, others ±5%RH) |
| Barometric Pressure | 300-1100 hPa, 8.9-32.5 inHg |
| Barometric Resolution | 0.1hPa, 0.1 inHg |
| Barometric Accuracy | ±3 hpa (at 0-60℃), ±5 hpa (-20-0℃) Accuracy is not specified in another temperature range |
| Sampling Points | 24K:T & 24K:RH, 16K:T, 16K:RH, 16K:Baro |
| Meter Size | 70(L) x50(W) x 23(H) mm |
| LCD Size | 30(L) x 18(W) mm |
| Operating Temperature | -30-70℃ |
| Operating RH% | Humidity <90% |
| Storage Temperature | -40-85℃ |
| Storage RH% | Humidity <90% |
| Weight | ±70g |
| Battery | 1PC 3.0V CR2 1 year life time while BLE broadcast & alarm is OFF 3 months life time while BLE broadcast is ON |
| Sampling Interval | 10 seconds to 120 minutes |
| Start Delay | 0-1440 minutes, 10 mins/step |
| Alarm Range | Programmable from -30 to 70℃ |
| Alarm Delay | 0-720 minutes, 5 mins/step |
| Alarm Type | Single Event, Cumulative, Disable |
| Operation Keys | 2 Keys (Start/Stop Key & Max/Min Key) |
| LED Indicator | REC, High /Low Alarm |
