Robust
The precision measurement module is protected by solid rubber. The Leica DISTO™ X–series is therefore particularly resistant. It is drop-tested up to 2m in height.
Protection class IP 65
The housing and keypad are water jet and dust protected. Cleaning the device under running water is no problem.
Tilt sensor and Smart Room
The combination of distance and tilt measurements allows you to easily determine horizontal distances with absolute precision. You can even use your measurement data to automatically generate realistic and scaled floor plans.
Rotatable display
The display automatically rotates in line with the orientation of the device; meaning you can easily read the screen from any angle
Technical Specification
Part Number
Description
Typ. distance measuring accuracy
± 1.0mm
Range
0.05 up to 150m
Measuring units
m, ft, in
X-Range Power Technology
yes
Distance in m
10, 50, 100m
Ø of the laser dot in mm
6, 30, 60mm
Tilt sensor
Tilt sensor accuracy to the laser beam
± 0.2°
Tilt sensor accuracy to the housing
Units in the tilt sensor
0.0°, 0.00%
Measuring range with DST 360
Horizontal
360°
Vertical
−64° to > 90°
2, 5, 10m
Typ. tolerance of the P2P function with DST 360
± 2, 5, 10mm
Levelling range with DST 360
± 5°
Memory for last measurements
20
Display illumination
Free software for Windows
Free App for iOS and Android
Smart Room support
General data interface
Bluetooth® Smart
Data interface for 3D point data with DST 360
Measurements per set of batteries
up to 4,000*
Service life of batteries
up to 8 h*
Multifunctional endpiece
Automatic reference detection for endpiece
Tripod thread
1/4"
Batteries
type AA 2 × 1.5 V
Protection class
IP65
2 m drop tested "applies to the DISTO device"
Yes
Dimensions
132 × 56 × 29 mm (H x D x W)
Weight with batteries
184 g
* Reduced when used with Bluetooth® or WLAN
